38 A-Class
Print Control (continued)
Menu Item Details
ROW OFFSET
Shifts the vertical SOP position on the label, where:
00.00in (0 – 99.99)
Is the offset distance; see Section 7.1 for media
details.
COLUMN OFFSET
Shifts the horizontal, left-justified SOP position to the
right without shifting the Label Width termination point
to the right, where:
00.00in (0 – 99.99)
Is the offset distance; see Section 7.1 for media
details.
PRESENT DISTANCE Sets the label stop position, where:
0.00in (0 - 4.00)
Is the label travel distance at output.
TOF PRECEDENCE
Allows an override of label format data when the form
length is exceeded, where:
DISABLED
Prints labels formats without TOF truncating.
ENABLED
Ends the label at the next TOF, truncating any print
data that extends past this mark.
CUSTOM ADJUSTMENTS
These selections independently change the listed
parameters, allowing slight mechanical compensations
sometimes evident when multiple printers share label
formats or for special printer-specific formatting
adjustments, where:
DARKNESS
32 (1 – 64)
Controls the printhead strobe time (see HEAT, above)
to fine-tune the solid areas of an image.
CONTRAST
32 (1 – 64)
Fine-tunes the gray areas of an image.
ROW ADJUST
XXXX (
–
XXX Æ XXXX)
Shifts the vertical SOP position to fine-tune ROW
OFFSET; see Appendix B.
;
If shifting in the negative direction, modify
PRESENT ADJUST (see below) by the same
amount.
COLUMN ADJUST
000 (
–
XXX Æ XXX)
Shifts both the horizontal SOP position and the LABEL
WIDTH termination point to the right to fine-tune
COLUMN OFFSET; see Appendix B.
PRESENT ADJUST
000 (
–
XXX Æ XXX)
Adjusts the label stopping position to fine-tune
PRESENT DISTANCE; see Appendix B.
