56 A-Class
Communications (continued)
Menu Item Details
SERIAL PORT C
Controls the settings for the Applicator Interface COM
C (J4) port, where the setting selections are the same
as those given for the SERIAL PORT A.
;
The maximum baud is 38.4K BPS.
SERIAL PORT D
Controls the settings for the Applicator Interface COM
D (J3) port, where the setting selections are the same
as those given for the SERIAL PORT A.
;
The maximum baud is 38.4K BPS.
PARALLEL PORT A
Controls the communications settings for Parallel Port
A, where:
PORT DIRECTION Allows printer data to be returned to the host, where:
UNI-DIRECTIONAL Returns no data (one-way communication).
BI-DIRECTIONAL Returns data (compliant back-channel operation); see
Section 2.2.2.1 for cable requirements.
PARALLEL PORT B
Controls the settings for the PARALLEL PORT B when
installed, where the setting selections are the same as
those given for the PARALLEL PORT A.
NIC ADAPTER
Controls the communications settings for the network
interface, where:
QUICK SETUP
;
Only when equipped with DMXNetII or DMXrfNetII.
Selects settings to configure basic Wired or WiFi
operations, where:
WIRED DHCP
Selects Wired operation, where:
NO
Exits the menu item without changing the current
settings.
YES
Returns the NIC Adapter to defaults then sets Wired
Discovery to “Enable” and Wireless to “Disable.”
WLAN UNSECURED
Selects WiFi operation, where:
NO
Exits the menu item without changing the current
settings.
YES
Returns the NIC Adapter default values then sets
Discovery to “Enable,” SSID to “Any,” and WLAN
network type to “Infrastructure.”
