64 A-Class
Diagnostics (continued)
Menu Item Details
TEST SCANNER
Tests the Linear Scanner, where:
ALIGNMENT TEST
Reads a bar code then displays the decoded data, the
code type and scan count, repeating.
SCAN TEST
Reads a bar code then displays the decoded data, the
code type and scan count, non-repeating.
TEST RFID
Tests RFID, where:
TAG DATA
Reads the data encoded on an RFID tag.
DEVICE VERSION
Displays the type and version of the encoding device.
TAG ID – HF ONLY
Reads then displays the High Frequency Tag ID
number.
PRINT TEST RATE (min)
Allows a label-to-label delay when batch printing Test
Labels, where:
000 (0 – 120)
Is the selected interval, in minutes.
SENSOR READINGS
Displays various sensor values (0 – 255), where:
THR TRAN RIBM 24V
127 159 093 175
PS HD RANK
00 254 125
Are readings for the printhead thermistor sensor
(THR), media “gap” (TRAN) or “reflective” (REFL)
sensor, ribbon sensor (RIBM), 24VDC power supply
sensor (24V), present sensor (PS), printhead assembly
sensor (HD), and printhead ranking resistor (RANK).
(The values given here are examples only.)
RIBBON SENSOR LIMITS
Displays ribbon sensor values for thermal transfer
equipped printers, where:
RIBBON ADC LOW
039
RIBBON ADC HIGH
250
Are the sensor readings. (The values given here are
examples only.)
