I-Class 17
3.1 Loading Media
Begin loading as follows:
n Raise the Access Cover.
o Rotate the Printhead Latch forward and raise the Printhead Assembly.
p Slide the Media Guide out away from the frame and then lower it to the
down position.
q If using roll media, the Media Hub can accept 3.0-inch (76mm) and 1.5-
inch (38mm) cores. To use 1.5-inch cores, first slide off the 3 Inch Hub by
grasping and then pulling it firmly outward.
r Proceed according to the type of media you are using: go to Section 3.1.1
for Roll Media or go to Section 3.1.2 for Fan-Fold Media.
