Refer to Section 2.1.1 for detailed information on print quality controls.
HEAT
10 (0-30)
Controls the ‘burn-time’ of the printhead. This
is the equivalent of Heat Setting on most label
software programs.
PRINT SPEED Controls the rate of label movement during
the printing process; see Appendix C.
FEED SPEED Controls the rate of label movement between
printing areas; see Appendix C.
REVERSE SPEED Controls the rate of label movement during
backup positioning for start of print, cutting or
present distance; see Appendix C.
ROW OFFSET
00.00in (0-99.99)
Shifts the vertical start of print position. This
is the user setting for row adjustment.
COLUMN OFFSET
00.00 in (0-99.99)
Shifts the horizontal, left-justified start of
print position to the right without shifting the
Label Width termination point to the right.
This is the user setting for Column Adjust.
PRESENT DISTANCE
0.00 in (0-4.00)
Sets the label stop position past the start of
print. When the next label format is received,
the printer will automatically backfeed to the
start position. If a quantity of more than one
label is printed without a present sensor
enabled, or if the present distance is set to
zero, the printer will operate without
reversing.
