38 I-Class
Print Control (continued)
CUSTOM ADJUSTMENTS
These factory adjustments independently
change the listed parameters to finely tune the
printer and compensate for slight mechanical
differences sometimes evident if multiple
printers share label formats. In addition, each
of the following adjustments has no factory
default setting and restoring factory defaults
will not affect these settings.
DARKNESS
XX (1-64)
Controls the printhead strobe time to fine-
tune the HEAT setting.
ROW ADJUST
XXX DOTS (-100 Æ 100)
Shifts the vertical start of print position in
dots upward or downward to fine-tune the
ROW OFFSET setting; see Appendix C.
COLUMN ADJUST
XXX DOTS (0-128)
Shifts both the horizontal start of print
position and the LABEL WIDTH termination
point to the right in dots to fine-tune the
COLUMN OFFSET setting; see Appendix C.
PRESENT ADJUST
XXX DOTS (0-128)
Adjusts the label stopping position in dots to
fine-tune the PRESENT DISTANCE setting;
see Appendix C.
