Datamax M-Class User Manual

M-Class 97
Mechanical
Width 9.8” (24.9 cm)
Depth 18.06” (45.9 cm)
Height 10.3” (26.2 cm)
Weight 21.5 lbs. (9.77 kg)
Operating Temperature
40° F to 95° F (4° C to 35° C)
Humidity
10% − 95% non-condensing
AC Input Voltage 90 – 132 or 180 – 264 VAC @ 47–63 Hz, auto-ranging.
Printing
Print Method Direct Thermal; Thermal Transfer (optional)
Print Speed 2 - 6 IPS (50 - 152 mm/s) M-4206 and M-4306
2 - 8 IPS (50 - 203 mm/s) M-4208
Resolution 203 dpi (8 dots/mm) M-4206 and M-4208
300 dpi (11.8 dots/mm) M-4306
Tear Bar Tear Down
DRAM Memory 4MB M-4206
8MB M-4208 and M-4306
FLASH Memory 2MB

Datamax M-Class Specifications

General

Print Method	Thermal Transfer/Direct Thermal
Resolution	203 dpi, 300 dpi
Print Speed	6 IPS (152 mm/s)
Interface	USB, Serial, Ethernet, Parallel
Media Sensor	Reflective and Transmissive
Supported Media Types	Labels, Tags
Media Thickness	0.0025" (0.0635 mm)
