5.4.3 Advanced Entry Calibration
Advanced Entry Calibration is the alternate method for special-case media types. The procedure has two parts:
1) You must list the sensor readings for the label and TOF values using different algorithms.
2) From your list the best algorithm is chosen, new readings taken and those values entered.

Advanced Entry Calibration will override all previous calibration settings; this method should be used only when Standard
Calibration has failed.
To perform an Advanced Entry Calibration:
Step Operator Action Displayed Message Comment
1
(Media should be loaded and the
appropriate Sensor Type selected.)
Turn ‘On’ the printer.
!
!!
VODBMJCSBUFE!
!
Wait until the printer initializes (about six seconds).
2
Press the
MENU
Key.
Raise the printhead assembly.
!
NFOV!NPEF!
NFEJB!TFUUJOHT!
!!
!
!
You are entering Menu Mode.
3
Press the
Key to enter the
Media Settings menu.
!
NFEJB!TFUUJOHT!
NFEJB!UZQF!
!!
!
!
See Section 5.1.2 for menu layout.
4
Press the
FWD
Key and scroll
to ‘Sensor Calibration’.
!
NFEJB!TFUUJOHT!
TFOTPS!DBMJCSBUJPO!
!!
!
Press the
Key to abort this procedure.
5
Press the
Key.
!
TFOTPS!DBMJCSBUJPO!
QFSGPSN!DBMJCSBUJPO!
!
You are entering the calibration submenu.
