Datamax M-Class User Manual

M-Class 73
Advanced Entry Calibration (continued)
Step Operator Action Displayed Message Comment
6 Press the
FWD
Key to scroll to
‘Advanced Entry’.
!
TFOTPS!DBMJCSBUJPO!
BEWBODFE!FOUSZ!
!
You are entering Advanced Entry Calibration.
7 Press the Key.
!
BEWBODFE!FOUSZ!
TFOTPS!MFWFMT!
!!
Press the
Key to abort this procedure.
8 Press the
FWD
Key.
!
BEWBODFE!FOUSZ!
TFOTPS!HBJO!
!!
You are beginning the Advanced Entry Calibration.
9 Press the Key.
Place the label under the Sensor
Eye Mark and lower the
printhead assembly.
!
HBJO!USBO!!!!!=zzz?!
+11!!!!!!!!=1!.!42?!
!
-OR-
HBJO!SFGM!!!!!=zzz?!
+11!!!!!!!!)1!.!42*!
If using preprinted media, ensure the label area under
the sensor is free of preprinted text, graphics or
borders.
10 Press the
Key to select
the setting (denoted by an ‘*’)
and then record the sensor
reading (the ‘yyy’ value) in a
table similar to the one shown
after Step 12, as a Label Value.
Next, press the
FWD
Key to
increment the Gain Number.
Repeat this step for each of the
Gain Numbers (00-32).
!
HBJO!USBO!!!!!=zzz?!
+11!!!!!!!!=1!.!42?!
!
-OR-
HBJO!SFGM!!!!!=zzz?!
+11!!!!!!!!)1!.!42*!
Where ‘yyy’ is a numerical value representing the
current sensor reading: useful in locating the best
sensor position.
 Note: Never position the sensor over a perforation
when recording a sensor reading.

Datamax M-Class Specifications

General

Print Method	Thermal Transfer/Direct Thermal
Resolution	203 dpi, 300 dpi
Print Speed	6 IPS (152 mm/s)
Interface	USB, Serial, Ethernet, Parallel
Media Sensor	Reflective and Transmissive
Supported Media Types	Labels, Tags
Media Thickness	0.0025" (0.0635 mm)
