74 M-Class
Advanced Entry Calibration (continued)
Step Operator Action Displayed Message Comment
11 Proceed according to your media
type:
Die-cut stock: strip the media
from the backing and then
reinsert it into the sensor; adjust
the Sensor Eye Mark over the
center of the backing.
Notched stock: adjust the
Sensor Eye Mark over the center
of the notch.
Reflective stock: Adjust the
Sensor Eye Mark over the center
of the facedown black mark.
Press the
Key to select
the setting and then record the
sensor reading in a table similar
to the one shown after Step 12,
as a TOF Value.
Next, press the
FWD
Key to
increment the Gain Number.
Repeat for each of the Gain
Numbers (00-32).
!
HBJO!USBO!!!!!=zzz?!
+11!!!!!!!!)1!.!42*!
!
Or, for reflective media:
HBJO!SFGM!!!!!=zzz?!
+11!!!!!!!!)1!.!42*!
Where ‘yyy’ is a numerical value representing the
current sensor reading: useful in locating the best
sensor position.
 Note: Never position the sensor over a perforation
when recording a sensor reading.
 Note: Do NOT move the position of the Media Sensor after it has been adjusted.

Datamax M-Class Specifications

General

Print Method	Thermal Transfer/Direct Thermal
Resolution	203 dpi, 300 dpi
Print Speed	6 IPS (152 mm/s)
Interface	USB, Serial, Ethernet, Parallel
Media Sensor	Reflective and Transmissive
Supported Media Types	Labels, Tags
Media Thickness	0.0025" (0.0635 mm)
