50 M-Class
System Settings (continued)
MEDIA COUNTERS ♦
Internal record of inches printed and time of use.
ABSOLUTE COUNTER
Shows the number of inches printed since being set at the factory. Not resettable.
RESETTABLE COUNTER
The number of inches printed since the last reset. User may reset.
RESET COUNTER
Resets the Resettable Counter to zero.
PRINT CONFIGURATION
Prints the effective configuration of the system. In addition, if settings were changed
that require a reset to become effective, this will be indicated with the ‘§’ symbol.
A bulleted item (•) indicates that it was changed via the host, but not saved in non-
volatile memory.
CONFIGURATION LEVEL ♦
To upgrade the application program (resident software) version of the printer, the
hardware and software compatibility levels must match for the update to be accepted.
This information is displayed here; it is also printed on a configuration label.
Each printer has a unique Key number in the following form:
vvvv-cwxx-yyyyyy-zzz
Where:
vvv
– represents the model number of the application loaded
cwx
– represents the hardware / software feature level, where:
c – represents the printer class.
w – represents hardware feature level of the main board.
xx – represents the software feature level:
10 = Standard DPL
20 = Internal CG Times Font
Software feature levels are accepted up to the ‘xx’ value (increases
beyond this level require an authorization code).
yyyyy
– is a manufacturing date code
PRINTER KEY
zz
– is a unique time stamp
APPLICATION VERSION
Displays the Application version of the printer’s firmware.
BOOT LOADER
Displays the Boot Loader version of the printer’s firmware.
UPGRADE PRINTER CODE
This function is used to upgrade the software feature level of the printer. Datamax
authorization is required.
UNLOCK FEATURE
This function is used to unlock the additional optional features within the printer.
Datamax authorization is required.
