Datamax M-Class User Manual

52 M-Class
System Settings (continued)
PEEL MODE
Specifies that a Feed operation be prevented when the label is presented and not
removed, or if the printer is to wait for the GPIO start of print signal.
ENABLED
Feed is inhibited according to the above criteria.
DISABLED
Feed is always enabled.
SECURITY ♦
Provides the user with the ability to password-protect all settings available through
the User Interface. Default password is: 1 2 3 4
SELECT SECURITY
Enable or disable the security feature of the User Interface.
MENU AND TEST
The Menu and Test areas will require a password before access is granted.
SECURE MENU
The Menu area will require a password before access is granted.
DISABLED
All menu items are accessible without protection.
MODIFY PASSWORD
Modify the numeric password required to access the menu system when security is
enabled.
UNITS OF MEASURE
Selects the measurement system in which the system’s settings are represented in the
menu system and on configuration labels.
IMPERIAL
Inch standard: lengths and counters given in inches.
METRIC
Metric standard: lengths given in millimeters and counters in centimeters.
INPUT MODE ♦
Defines the type of printer language.
DPL
Standard DPL processing.
LINE
Standard DPL processing with addition Line mode Template processing enabled.
Line Mode exacts data terminated by a carriage return to be inserted in a DPL
template and printed.

Datamax M-Class Specifications

General

Print Method	Thermal Transfer/Direct Thermal
Resolution	203 dpi, 300 dpi
Print Speed	6 IPS (152 mm/s)
Interface	USB, Serial, Ethernet, Parallel
Media Sensor	Reflective and Transmissive
Supported Media Types	Labels, Tags
Media Thickness	0.0025" (0.0635 mm)
