Datamax M-Class User Manual

70 M-Class
Standard Calibration (continued)
Step Operator Action Displayed Message Comment
7 Proceed according to your media
type:
Die-cut stock: strip the media
from the backing and then
reinsert it into the sensor; adjust
the Sensor Eye Mark over the
center of the backing.
Notched stock: adjust the
Sensor Eye Mark over the center
of the notch.
Reflective stock: Adjust the
Sensor Eye Mark over the center
of the facedown black mark.
Continuous stock: go to Step 8.
Press the key to continue.
TDBO!CBDLJOH!
QSFTT!FTD!LFZ!!!=zzz?!
!
Or, for reflective media:
!
TDBO!NBSL!
QSFTT!FTD!LFZ!!!=zzz?!
This sets the parameter for the ‘gap’ or ‘mark’ value.
Where ‘yyy’ is a numerical value representing the
current sensor reading: useful in locating the best
sensor position.
 Note: Never position the sensor over a perforation
when recording a sensor reading.
 Note: Do NOT move the position of the Media Sensor after it has been adjusted.
8 Position the label (and backing,
if any) under the Sensor Eye
Mark.
 Note: If using preprinted
media, ensure the label area
under the sensor is free of
preprinted text, graphics or
borders.
Press the key to continue.
!
TDBO!QBQFS!
QSFTT!FTD!LFZ!!=zzz?!
!
!
This sets the parameter for the ‘paper’ value.
Where ‘yyy’ is a numerical value representing the
current sensor reading.

Datamax M-Class Specifications

General

Print Method	Thermal Transfer/Direct Thermal
Resolution	203 dpi, 300 dpi
Print Speed	6 IPS (152 mm/s)
Interface	USB, Serial, Ethernet, Parallel
Media Sensor	Reflective and Transmissive
Supported Media Types	Labels, Tags
Media Thickness	0.0025" (0.0635 mm)
