Congratulations on your RL4 printer purchase. The RL4 printer
family, hereafter referred to as ‘the printer’, blends the rugged
durability with state-of-the-art electronics and user-friendly
features to redefine the standard in portable thermal printers. The
printer’s RS-232 serial, USB, or optional wireless LAN or Bluetooth
®
connectivity allows easy interfacing to any host system.
This manual provides all the information necessary to operate the
printer.
To print labels or receipts, simply refer to the instructions included
with the software you have chosen to create the labels. A
Windows
®
printer driver can be found on our website (www.datamax-oneil.com). If you wish to write a
custom program, a copy of the Programmer’s Manual can also be found on our website.
1
1
1
.
.
.
2
2
2
U
U
U
n
n
n
p
p
p
a
a
a
c
c
c
k
k
k
i
i
i
n
n
n
g
g
g
After removing the printer from the packaging material, check the contents. The following items should be
included:
 Printer
 Belt Clip
 Documentation
 Any special or additionally purchased items
Additional Requirements:
The following items are necessary for generating labels from your printer. Contact your customer support
or sales representative for advice on which media and software may best be suited for your application.
 NETira CT Configuration Software, version 1.0.0.0 or greater. Available for download at
www.datamax-oneil.com
 Serial Cable (210164-100 or 210191-101)
 Applicable label media or receipt paper

It is a good idea to save all packaging materials in the event that shipping the printer is ever
required.
The table below identifies the P/N and printers features of the RL4 printer
MODEL NUMBER STANDARD FEATURE(S) OPTIONAL FEATURE(S)
H40000-100 SERIAL/USB -
H41000-100 SERIAL/USB BLUETOOTH
H42000-100 SERIAL/USB 802.11
H40001-100 SERIAL/USB LINERLESS
H41001-100 SERIAL/USB BLUETOOTH, LINERLESS
H42001-100 SERIAL/USB 802.11, LINERLESS
The model number can be found on the label located on the back of the printer.
