AP25 Installation and Operating Guide Version 1.00
Appendix H. Serial Command AP! H-3 Document #: 9301H79500 Ver. 1.00
1. System Information
Returns system versions and MAC address
Command: @SYSTEM <cr>
Operation
Response: VER<space>[Version]<LF>
VERDATE<space>[Date]<LF>
MAC<space>[Mac Address]<CR><\0>
Read
Parameters
Version Software version number
Date Software date/time
Mac Address AP25 MAC address
2. Identify
Get system identify information. Mostly used in discovery protocol.
Command: @IDENTIFY<cr>
Operation
Response: AP20<space>
[IP]<space>
[Circuit]<space>
[Theater]<space>
[Screen]<cr>
Read
Parameters
AP20 Confirms AP25 is connected at this address
[IP] IP address (useful after broadcast command)
[Circuit] Circuit information
[Theater]
Theater information
[Screen]
Screen information
3. Health
Enquiry for system health data.
Command: @HEALTH [SUB CMD]<cr>
Operation
Response: (depends on SUB_CMD)
Read
SUB_CMD
TEMPERATURE
Returns t1, t2, t3 Celsius temperatures where:
t1: H331 board temperature
t2: H332 board temperature
