Passport 2®/Passport 2 LT™ Service Manual 0070-10-0441 5 - 3
Replacement Parts
6A
6B
8
4
6
START KEYPAD INSTALLATION
AT ENCODER END
MOUNTING HARDWARE
(LOCKWASHER AND NUT)
SUPPLIED WITH ITEM 5
TORQUE: 13IN - LB
2 PLACES
7
22
REF
REF
36
14
15
4 PLACES
2 PLACES
17
ATTACH GROUND STRAP
CONDUCTIVE SURFACE
IS TO CONTACT RAIL
GROUND STRAP IS PART OF
THE KEYPAD (ITEM 6)
SERIAL NUMBER LABEL
LOCATE APPROX AS
SHOWN
11
5
9
1
3
2 PLACES
10
32
2 PLACES
7
16
39
4
2 PLACES
2
6 PLACES
37
24
36
22
2
13
40
2 PLACES
35
33
2 PLACES
DO NOT CREASE
42
(EL DISPLAY)
Isometric Drawing
FRONT ASSEMBLY EL
Added 03/10/00
