Passport 2®/Passport 2 LT™ Service Manual 0070-10-0441 5 - 5
Replacement Parts Parts List Front Housing
5.1 Parts List Front Housing
ITEM NO. DESCRIPTION PART NO.
1. Speaker w/ cable assembly 0012-00-0257-06
2. Screw Pan Hd 4-40 x 3/16 0212-12-0403
3. Screw Pan Hd 4-40 x 5/16 0212-12-0405
4. Screw Pan Hd 6-32 x 5/16 0212-12-0605
5. (Navigator) Encoder w / nut & washer 0311-00-0132
6. Keypad Membrane 0331-00-0117-01
6. Keypad Membrane 0331-00-0129
6a. Keypad Overlay w/ IBP 0330-00-0029-XX
6b. Keypad Overlay w/o IBP 0330-00-0029-XX (See
“Keypad Overlay Table
P/N 0330-00-0029-XX”
on page 5-7.)
7. Foot (4 required) 0348-00-0190
8. Knob, Rotary 0366-00-0101
9. Front Housing 0380-00-0338-01
9. Front Housing (LT) 0380-00-0338-02
10. Speaker Holder 0380-00-0352
11. Serial Number Label (Front Housing) 0334-00-1560
12. PCB Interconnect Panel Bd. (LCD Display) 0670-00-0686
13. Cable EL, (display to Interconnect Bd.) 0012-00-1005
14. EL Display Assembly 0160-00-0044
15. Screw Flat Head 0212-17-0807
16. (EL) Gasket 0348-00-0189
17. Mount Rail (EL Right Side) 0436-00-0138
18. Cable LCD Color (display to Interconnect Bd) 0012-00-1208
19. Cable LCD Color (DC/AC Inverter) 0012-00-1221
20. LCD Color Display Kit 0040-00-0331
20. LCD Color Display with Anti-Glare 0160-00-0071-01
20. LCD Color Display NEC Bonded/Anti-Glare
For use in units with serial number TSXXXX-E8 and below.
0160-00-0087-01
20. LCD Color Display NEC Bonded/Anti-Glare
For use in units with serial number TSXXXX-E8 and above.
0160-00-0112-01
21. Screw Pan Hd 2-56 x 3/16 0212-12-0203
22. Screw Pan Hd 4-40 x ¼ 0212-12-0404
23. Screw Flat Hd 4-40 x ¼ 0212-14-0404
24. Screw Flat Hd 4-40 x ½ 0212-14-0408
25. Washer flat #4 0221-00-0004
26. Gasket 0348-00-0204
27. N/A
28. Bracket 0406-00-0794
29. Bracket Cable Retainer 0406-00-0795
30. Mount Rail (LCD Left side) 0436-00-0178
