Passport 2®/Passport 2 LT™ Service Manual 0070-10-0441 5 - 15
Replacement Parts Parts List Rear Housing
5.2 Parts List Rear Housing
ITEM NO. DESCRIPTION PART NUMBER
1. Rear Housing Assembly (S/N - TM06075-G3 or higher) 0380-00-0339-01
1. Rear Housing Assembly 0380-00-0339-02
2. Foot 0348-00-0190
3. Handle 0367-00-0061
4. Pin, Handle (2 required) 0226-00-0017
5. Cover/Docking Connector 0198-00-0037
6. Recorder Mount Bracket (AR-42) 0406-00-0741
6. Bracket Recorder Mount (XE-50) 0406-00-0745
7. PCB Recorder Interface Board (AR-42) 0670-00-0695
7. PCB Recorder Interface Board (XE-50) 0670-00-1153
8. Batteries, 12 Volt Sealed Lead Acid 0146-00-0043
9. Fitting NIBP Connector 0103-00-0503
10. Fan w/ cable assembly 9.89 CFM 0012-00-1622-01
10a. Screw Pan Hd 6-32 x 9/16 0212-12-0609
11. Shield, Ground Plate 0386-00-0243
12a. PCB Main CPU Board (12 lead option)
S/N CM 20000/TM1000-X or higher
0670-00-0739-01
12b. PCB Main CPU Board (12 lead option) 0670-00-0739-03
12c. PCB Main CPU Board
(use with S/N TS XXXX-J5 or higher)
0670-00-0782-03
13. Cable Interconnect Panel Bd to Main CPU Bd 0012-00-1210
14. Switch w/ cable assembly 0012-00-1231
15. NIBP Module Assembly 0670-00-0746-01
15. NIBP Module Assembly 0670-00-0798-01
16. Pump Assembly w / cable (NIBP) 0012-00-1249
17. NIBP Pump Bracket 0406-00-0750
18. Cable Assembly NIBP to Main CPU Bd 0012-00-1211
19. Cover, Power Supply (with DC connector) 0198-00-0028
19. Cover, Power Supply (w/o DC connector) 0198-00-0050
20. Battery Door 0380-00-0349
21. Grounding bracket/ strap (metal) 0346-00-0044
21. Grounding bracket/ strap (plastic) 0346-00-0049
22. Snap Cover, Blank 0198-00-0027
23. Screw Pan Hd 6-32 x 5/16 0212-12-0605
24. Screw Pan Hd 6-32 x 7/16 0212-12-0607
25. Screw Pan Hd 4-40 x 3/16 0212-12-0404
25a. Screw Pan Hd 4-40 x 3/16 0212-12-0403
26. Screw Pan Hd 4-40 x 11/16 0212-12-0412
27. Screw Pan Hd 4-40 x 11/16 0212-12-0407
28. Screw Pan Hd 4-40 x 3/16 0212-12-0603
29. Screw Pan Hd 4-40 x 1/2 0212-10-0408
N/A - Not available
