Parts List Rear Housing Replacement Parts
5 - 16 0070-10-0441 Passport 2®/Passport 2 LT™ Service Manual
30. PCB Nellcor SpO
2
Module with OxiSmart 0671-00-0162
30. PCB Nellcor SpO
2
Module with Oximax (Nell3) 0671-00-0066
31. PCB Nellcor Interface 0670-00-0696
31. SPO
2
Interface Board 0670-00-0785-01
-02 or -03
32. Cable, Nellcor Interface to Main CPU Board 0012-00-1233
32. Cable, Interface to Main CPU Board for
0998-00-0900-XXXX
0012-00-1596
33. Cable Assembly Nellcor SpO
2
0012-00-1356
34. PCB Masimo (MS-3) SpO
2
Module 0671-00-0055
35. Cable Masimo Module to Main CPU 0012-00-1201
36. Spacer 0361-45-0403
37. Cable Assembly Masimo SpO
2
0012-00-1308
38. Battery Holder Assembly (metal, SLA) 0997-00-0502
38. Battery Holder Assembly (plastic, SLA) 0997-00-0972-01
38. Battery Holder Assembly (plastic, Li-ion) 0997-00-0972-02
39. Power Supply/ Charger Assembly, SLA 0014-00-0190E
39. Power Supply/ Charge Assembly, SLA 0014-00-0250
39. Power Supply/ Charge Assembly, Li-ion/SLA 0014-00-0251
40. Button/PCMCIA Slot B
41. Cable CO
2
Module to Main CPU Bd (MediCO
2
) 0012-00-1200
41. Cable CO
2
Module to Main CPU Bd (miniMediCO
2
) 0012-00-1683-01
NS Double Sided Tape 0215-00-0115
42. Screw Pan Hd Nylon 4-40 x ¼ 0212-01-0404
43. Screw Pan Hd # 6 x 1 ¼ 0212-12-0620
44. Screw Pan Hd # 6 x 5/16 0212-12-0405
45. Paper Holder Recorder Door 0352-00-0051
46. Recorder Assembly (AR-42 special) 0683-00-0465E01
46. Recorder Assembly (XE-50) 0683-00-0501-01
46. Recorder Assembly (XE-50)
0998-00-0170-XXXXX (S/N TM20000-XX or higher)
0998-00-0900-XXXXX (S/N TS03000-XX or higher)
0683-00-0501-02
47. Recorder Plate, Blank 0370-00-0017-03
48. Recorder Plate, Blank (XE-50) 0380-00-0482-02
49. MediCO
2
Module Assembly (Oridion) 0671-00-0164-03
49. miniMediCO
2
Module Assembly (Oridion) 0671-00-0089-01
50. Retainer C-Clip 0226-00-0018
51. Screw Pan Head 6-32 x ¼ 0212-12-0604
52. Standoff Male / Female 6-32 x 0.250 long 0361-27-0250
53. Cable, Patient Connector to Main CPU Bd 0012-00-1206-01
54. Strap, Battery Door 0346-00-0047
55. Connector Panel (Masimo w/ CO
2
) 0380-00-0348-01
55. Connector Panel (Masimo w/o CO
2
) 0380-00-0348-02
ITEM NO. DESCRIPTION PART NUMBER
N/A - Not available
