Passport 2®/Passport 2 LT™ Service Manual 0070-10-0441 5 - 17
Replacement Parts Parts List Rear Housing
55. Connector Panel (Nellcor w/CO
2
) 0380-00-0348-03
55. Connector Panel (Nellcor w/o CO
2
) 0380-00-0348-04
55. Connector Panel (Nellcor Oximax w/ CO
2
) 0380-00-0348-05
55. Connector Panel (Nellcor Oximax w/o CO
2
) 0380-00-0348-06
56. CO
2
Exhaust Connector w/nut 0103-00-0489
57. CO
2
Input Connector Door 0380-00-0355
58. Spring 0214-00-0236
59. Screw Self Tapping #4 x 3/16 0213-09-0403
60. Washer Flat 0.470 OD 0.119 ID 0221-00-1014
61. PCB Patient Connector Bd AAMI w/ IBP 0670-00-0682-01
61. PCB Patient Connector Bd AAMI w/o IBP 0670-00-0682-02
61. PCB Patient Connector Bd HP w/ IBP or w/o IBP 0670-00-0680-01
62. Label, Patient Connector 0334-00-1501-XX
(See Table 6-2)
63. Label, Right Side 0334-00-1528
64. Label, Information Passport2 0334-00-1500
65. Label, Part Number / Serial Number N/A
66. Label, Software Part Number N/A
67. Label, Loading Recorder Paper (AR-42) 0334-00-1431
67. Label, Loading Recorder Paper (XE-50) 0334-00-2674
68. Bracket Plastic Slotted (MediCO
2
) 0406-00-0805
68. Bracket Plastic Lower (miniMediCO
2
) 0406-00-0885
69. Bracket Plastic Thru-Hole (MediCO
2
) 0406-00-0783
69. Bracket Plastic Upper (miniMediCO
2
) 0406-00-0879
NS PCMCIA Extended Trend Card 0996-00-0052-01
NS PCMCIA Transfer Card 0996-00-0051-01
NS PCMCIA Filler Card (Blank) 0380-00-0372
70. Insulator, Nellcor SpO
2
Interface Board 0349-00-0322
71. Clamp, Cable 0343-00-0007
72. CO
2
Input Assembly 0012-00-1400
73. Nut, Hex 1/4 x 32 (use on NIBP fitting) 0220-00-0004
74. Washer, Flat 0.473 OD - 0.260 ID
use on NIBP fitting)
0221-00-1023
75. Mounting Bracket, 12 Lead 0380-00-0399-01
76. Screw Pan Head #6 - 32 x 1 1/2 0212-12-0624
77. Screw Pan Head #6 - 32 x 3/4 0212-12-0612
78. Bracket Magnetic Shield 0406-00-0833
79. Standoff Plastic 0361-08-0017
80. Cable Tie Anchor 0125-00-0023
81. Washer Shoulder .140 OD, -115 ID 0221-00-1026
82. Screw Pan Head 0212-12-0418
83. Cable Tie 0125-01-0001
ITEM NO. DESCRIPTION PART NUMBER
N/A - Not available
