Datavideo NVS-40D - How to Install 2.5 Ssd;Removable Hdd

20
Note: The 2.5” SSD/HDD must be installed in the enclosure and inserted into the
HDD tray on the front panel of the NVS-40 to start recording.
4.2 How to Install 2.5” SSD/Removable HDD
How to Assemble 2.5” SSD/HDD in Removable Enclosure.
1. Remove the top cover
of the SSD/HDD
enclosure.
2. Place the SSD/HDD
into the enclosure,
cover the top cover
back and then screw
four screws for both
sides as shown as the
diagram.
