Dell 7070 Tower User Manual

Installing the VGA daughter board
1 Align the VGA daughter board with the screw holder on the system board.
2 Tighten the screw to secure the VGA daughter board to the system board.
3 Insert the VGA connector into the slot at the back of the computer.
4 Tighten the screws to secure the VGA connector to the computer.
5 Close the front bezel door.
6 Install the:
• bezel
• cover
7 Follow the procedure in After Working Inside Your Computer.
Removing the intrusion switch
1 Follow the procedure in Before Working Inside Your Computer.
2 Remove the:
• cover
• bezel
3 Open the front bezel door.
4 To remove the intrusion switch:
a Disconnect the intrusion switch cable from the connector on the system board [1].
b Unroute the intrusion switch cable from the fan grommet [2].
c Slide the intrusion switch and lift it away from the computer [3].
Removing and installing components 16

Dell 7070 Tower Specifications

General

Form Factor	Tower
RAM	Up to 64GB DDR4
Graphics	Intel UHD Graphics 630
Operating System	Windows 10 Pro
Ports	USB 3.1 Gen 1
Power Supply	200W
Optical Drive	Optional DVD-ROM or DVD-RW
