4 Install the heatsink assembly.
5 Close the front panel door.
6 Install the:
a Front bezel
b Side cover
7 Follow the procedure in After working inside your computer.
System fan
Removing system fan
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a Side cover
b Front bezel
c Intrusion switch
3 To remove the system fan:
a Disconnect the system fan cable from the connector on the system board [1].
b Stretch the grommets to remove the grommets securing the fan to the computer[2].
c Slide the system fan out of the computer [3].
60
Removing and installing components
