Dell 7070 Tower - 3.5-Inch Hard Drive

4 Install the:
a Front bezel
b Side cover
5 Follow the procedure in After working inside your computer.
3.5-inch hard drive
Removing 3.5–inch hard drive from the hard drive bracket
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a Side cover
b Front bezel
c 3.5-inch HDD assembly
3 To remove the hard drive :
a Pull one side of the hard drive bracket to disengage the pins on the bracket from the slots on the hard drive [1].
b Lift the hard drive out of the hard drive bracket [2].
Removing and installing components
25
