Dell 7070 Tower - M.2 Ssd; Removing M.2 SSD

2 Install the:
a Front bezel
b Side cover
3 Follow the procedure in After working inside your computer.
M.2 SSD
Removing M.2 SSD
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a Side cover
b Front bezel
3 Open the front panel door.
4 To remove the M.2 SSD:
a Remove the single screw that secures the SSD to the system board [1].
b Slide the M.2 SSD from the connector on the system board [2].
Removing and installing components
33
