Dell 7070 Tower - Intrusion Switch; Removing Intrusion Switch

2 Close the front panel door.
3 Install the:
a Front bezel
b Side cover
4 Follow the procedure in After working inside your computer.
Intrusion switch
Removing intrusion switch
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a Side cover
b Front bezel
3 Open the front panel door.
4 To remove the intrusion switch:
a Disconnect the intrusion switch cable from the connector on the system board [1].
b Unroute the intrusion switch cable from the fan grommets [2].
c Slide the intrusion switch and push it to remove from the computer [3].
Removing and installing components
45
