Dell 7070 Tower - Expansion Card; Removing Pcie Expansion Card

2 Close the front panel door.
3 Install the:
a Front bezel
b Side cover
4 Follow the procedure in After working inside your computer.
Expansion card
Removing PCIe expansion card
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a Side cover
b Front bezel
3 Open the front panel door.
4 To remove the PCIe expansion card:
a Pull the release latch to unlock the PCIe expansion card [1].
b Push the card retention latch [2], and lift the PCIe expansion card out of the computer [3].
Removing and installing components
39
