Removing the Primary Hard-Drive | 25
4 Disconnect the interposer from the primary hard-drive connector.
5 Remove the screws that secure the primary hard-drive to the primary hard-drive
bracket.
6 Slide and lift the primary hard-drive off the primary hard-drive bracket.
1 interposer 2 primary hard-drive connector
3 screws (4) 4 primary hard-drive bracket
5 primary hard-drive
