Removing the Secondary Hard-Drive (optional) | 19
Procedure
1 Remove the screws that secure the secondary hard-drive assembly to the computer
base.
2 Carefully lift the secondary hard-drive assembly and then lift the latches to release
the secondary hard-drive cable from the system-board connector.
3 Lift the secondary hard-drive assembly off the computer base.
1 secondary hard-drive cable 2 connector latches (2)
3 screws (4) 4 secondary hard-drive assembly
