24 | Removing the Primary Hard-Drive
Procedure
1 Lift the pull-tab to disconnect the primary hard-drive cable from the system-board
connector.
2 Remove the screws that secure the primary hard-drive assembly to the computer
base.
3 Lift the primary hard-drive assembly off the computer base.
1 pull-tab 2 primary hard-drive cable
3 screws (4) 4 primary hard-drive assembly
book.book Page 24 Monday, June 24, 2013 10:53 AM
