58 | Removing the Subwoofer
Procedure
1 Remove the screws that secure the subwoofer to the computer base.
2 Disconnect the subwoofer cable from the system-board connector.
3 Note the subwoofer cable routing and remove it from the routing guide.
4 Lift the subwoofer along with its cable away from the computer base.
1 subwoofer cable 2 subwoofer cable routing
3 screws (3) 4 subwoofer
