Removing the Wireless Mini-Card | 27
Removing the Wireless Mini-Card
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
"Before You Begin" on page 9. After working inside your computer,
follow the instructions in "After Working Inside Your Computer" on
page 11. For additional safety best practices information, see
the Regulatory Compliance Homepage at
dell.com/regulatory_compliance.
Prerequisites
1 Remove the base cover. See "Removing the Base Cover" on page 12.
2 Remove the battery. See "Removing the Battery" on page 14.
Procedure
1 Disconnect the antenna cables from the wireless mini-card.
2 Remove the screw that secures the wireless mini-card to the system board.
1 screw 2 wireless mini-card
3 antenna cables (2)
1
3
2
