62 | Replacing the Tron Lights
Replacing the Tron Lights
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
"Before You Begin" on page 9. After working inside your computer,
follow the instructions in "After Working Inside Your Computer" on
page 11. For additional safety best practices information, see
the Regulatory Compliance Homepage at
dell.com/regulatory_compliance.
Procedure
1 Connect the tron lights to the optical fibres.
2 Route the tron-light cables through the routing guides on the computer base.
3 Connect the tron-light cables to their respective connectors on the system-board.
Postrequisites
1 Replace the subwoofer. See "Replacing the Subwoofer" on page 59.
2 Follow the instructions from step 5 to step 10 in "Replacing the Palm Rest" on
page 36.
3 Follow the instructions from step 8 to step 10 in "Replacing the Secondary Hard-Drive
(optional)" on page 22.
4 Replace the battery. See "Replacing the Battery" on page 15.
5 Replace the base cover. See "Replacing the Base Cover" on page 13.
6 Follow the instructions in "After Working Inside Your Computer" on page 11.
