Removing the Tron Lights | 61
Procedure
1 Disconnect the tron-light cables from the system-board connectors.
2 Note the routing of the tron-light cables and remove the cables from the routing
guides.
3 Disconnect the tron lights from the optical fibers.
4 Lift the tron lights along with their cables off the computer base.
1 tron-lights cables 2 tron lights (4)
3 routing guides (3)
