52 | Removing the Coin-Cell Battery
Procedure
1 Disconnect the coin-cell-battery cable from the system-board connector.
2 Peel the coin-cell battery off the system board.
3 Lift the coin-cell battery along with its cable off the system board.
1 system board 2 coin-cell battery cable
3 coin-cell-battery
