68 | Removing the Display Assembly
Procedure
1 Close the display and turn the computer over.
2 Disconnect the display and camera cables from the system-board connectors.
3 Disconnect the antenna cables from the wireless mini-card.
4 Remove the screws that secure the display assembly to the computer base.
1 wireless mini-card 2 antenna cables (2)
3
camera cable
4 display cable
5screws (2)
