Removing the Power-Adapter Port | 65
3 Remove the screw that secures the power-adapter port bracket to the computer
base.
4 Lift the power-adapter port bracket and keep it aside.
5 Disconnect the power-adapter port cable from the system-board connector.
6 Lift the power-adapter port off the computer base.
1 power-adapter port 2 power-adapter port cable
3 power-adapter port bracket 4 screw
4
1
2
3
