86 | Removing the Display Light Boards
2 Disconnect the camera cable from the camera-module connector.
3 Note the routing of the camera cable and peel off the cable from the display
back-cover.
4 Remove the screws that secure the display light boards to the display back-cover.
5 Lift the display light boards off the display back-cover.
1 screws (3) 2 display light boards (3)
3 camera cable 4 camera-module connector
