90 | Removing the System Board
2 Remove the screws that secure the system board to the computer base.
3 Lift the system board at an angle and remove the ports on the system board from the
slots on the computer base.
4 Turn the system board over and keep it on a clean surface.
5 Follow the instructions from step 1 to step 2 in "Removing the Processor Heat-Sink"
on page 92.
1 system board 2 screws (6)
book.book Page 90 Monday, June 24, 2013 10:53 AM
