106 | Removing the Wireless Mini-Card
Procedure
1 Disconnect the antenna cables from the connectors on the wireless Mini-Card.
2 Remove the screw that secures the wireless Mini-Card to the system board.
3 Lift the wireless Mini-Card away from the system-board connector.
1 antenna cables (2) 2 wireless mini-card
3 screw
