14 | Removing the Base Cover
Removing the Base Cover
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
"Before You Begin" on page 11. For additional safety best practices
information, see the Regulatory Compliance Homepage at
dell.com/regulatory_compliance.
Procedure
1 Remove the screws that secure the base cover to the computer base.
2 Slide the base cover towards the rear of the computer and lift it off the computer
base.
1 screws (3) 2 base cover
Book.book Page 14 Friday, June 28, 2013 11:10 AM
