84 | Replacing the Subwoofer
Replacing the Subwoofer
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
"Before You Begin" on page 11. For additional safety best practices
information, see the Regulatory Compliance Homepage at
dell.com/regulatory_compliance.
Procedure
1 Align the screw holes on the subwoofer with the screw holes on the computer base.
2 Tighten the captive screws that secure the subwoofer to the computer base.
3 Route the subwoofer cable through the routing guides on the computer base and
then connect the subwoofer cable to its connector on the system board.
Postrequisites
1 Replace the speaker. See "Replacing the Speakers" on page 81.
2 Follow the instructions in "After Working Inside Your Computer" on page 13.
