26 | Removing the Hard Drive(s)
Procedure
1 Disconnect the hard-drive cable from its connector on the system board.
2 Loosen the captive screws that secure the hard-drive assembly to the computer base.
3 Using the pull-tab, lift the hard-drive assembly out of the computer base.
1 hard-drive cable 2 captive screws (4)
3 pull tab 4 hard drive
Book.book Page 26 Friday, June 28, 2013 11:10 AM
