62 | Removing the Camera Module
Procedure
1 Remove the screw that secures the camera module to the display back-cover.
2 Disconnect the camera cable from the camera-module connector.
3 Pry and lift the camera module off the display back-cover.
1 screw (1) 2 camera module
3 camera-cable connector
1
2
3
