80 | Removing the Speakers
Procedure
1 Disconnect the speakers cable from its connector on the system board.
2 Note the speakers cable routing and remove the cable from the routing guides on the
computer base.
3 Remove the screws that secure the speakers to the computer base.
4 Lift the speakers, along with the speaker cable, off the computer base.
1 speakers (2) 2 speakers-cable routing
3 screws (4) 4 speakers cable
