16 | Removing the Battery Pack
Removing the Battery Pack
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
"Before You Begin" on page 11. For additional safety best practices
information, see the Regulatory Compliance Homepage at
dell.com/regulatory_compliance.
Prerequisites
Remove the base cover. See "Removing the Base Cover" on page 14.
Procedure
1 Remove the screws that secure the battery to the computer base.
2 Disconnect the battery cable from its connector on the system board.
3 Lift the battery pack away from the computer base.
1 battery cable 2 screws (2)
3 battery pack
Book.book Page 16 Friday, June 28, 2013 11:10 AM
