Removing the Optical Drive | 23
4 Remove the screws that secure the optical-drive bracket to the optical drive.
5 Lift the optical-drive bracket off the optical drive.
6 Remove the interposer from the optical drive.
1 optical-drive bracket 2 interposer
3 screws (4)
3
2
1
