Removing the Palm Rest | 41
4 Turn the computer over.
5 Carefully pry out the palm-rest assembly from the two tabs along the rear edge of the
computer, and then ease the palm-rest assembly from the computer base.
CAUTION: Carefully separate the palmrest from the computer base
to avoid damage to the palmrest.
6 Lift the palm-rest assembly off the computer base.
7 Remove the status-light board. See "Removing the Status-Light Board" on page 47.
8 Remove the power-button board. See "Removing the Power-Button Board" on
page 45.
1 palm-rest assembly
