52 | Removing the Keyboard
3 Lift the connector latch and pull the pull-tab to disconnect the keyboard cable from
the respective connector.
4 Remove the screws that secure the keyboard to the palm-rest assembly.
5 Lift the keyboard off the palm-rest assembly.
1 screws (2) 2 keyboard cable
2
1
