92 | Removing the Video Card(s)
3 Remove the screws that secure the video-card(s) to the system board.
4 Lift and slide the video-card(s) along with heat sink(s) out to disconnect it from the
connectors on the system board.
Primary Video Card
Secondary Video Card
1 primary video card 2 screws (2)
1 secondary video card 2 screws (2)
2
1
1
2
